4-Channel Mobile DVR MC904 with 4G

Availability:

In Stock


Main Features

  • 4-CH Camera: The device could supports 4 channel camera simultaneous working.
  • H.265/H.264 encode: H.265/H.264 encoding and decoding to improve the memory space utilization.
  • Multiplex I/O: Support up to 4 digital input interfaces, 1 digital output interface, 2 RS232 interfaces. External devices such as RFID reader, fuel sensors and PTZ can be integrated.
  • Large Memory: Mini size as no hard Disk. Supports 2 maximum 512GB SD card.
  • AI Algorithm: The device supports DMS, ADAS and BSD three algorithms.
  • Convenient Operation: Configured with a graphical menu operation interface, you can use the mouse or the remote control to configure the parameters.
Payment Options

Secure Payment Options
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
NB: Prices are subject to change without notice

KShs 36,500.00 KShs 40,000.00 VAT exc

In Stock

4-Channel Mobile DVR MC904 with 4G

Are you looking for a vehicle camera for your cargo truck? The MC904 is a 4G MDVR that supports 4 channels of 1080p video input. It features a unique design without a hard drive and supports two 512GB SD cards. With its compact size, it is easy to install and transport. Access the video live stream from all the 4 cameras in your smartphone or your laptop. This is an ideal video telematics solution for fleet managers and truck owners. Besides, it is integrated with GPS antenna for real-time vehicle location monitoring. The MC904 MDVR is more than your  dashcam as it features excellent AI features such as ADAS, BSD and DMS

The device has an aluminum alloy shell, ensuring good heat dissipation. It supports emergency alarm function, 4-channel digital signal input, 1-channel digital signal output, and 2 RS232 serial ports for connecting various peripherals. Additionally, the device is equipped with built-in AI algorithms, supporting ADAS, DMS, BSD, and 360-degree video stitching. It effectively helps drivers enhance transportation safety and reduce pedestrian and vehicle accidents

Category: Tag:

Hardware

Operation systemLinux
CPUARM Cortex CA9 Dual-Core +NPU@0.7
GNSSGPS+BDS(with external G-mouse)
MemoryDDR 512M
SD card(Max. 512G)*2
G-sensor3-axis accelerometer
SpeakerYes
MicYes
Sim cardStandard SIM
LEDRed(power),Green(Internet & video  recording)
I/O ports4*digital inputs, 2*RS232 port or 1*RS485 port and 1*RS232
Others

Network

CellularLTE + WCDMA + GSM
BandsMC904-EU:
FDD LTE: B1/B3/B5/B7/B8/B20/B28
TDD LTE: B38/B40/B41
WCDMA: B1/B5/B8
GSM:B3/B8
MC904-LA:
FDD LTE: B1/B2/B3/B4/B5/B7/B8/B28/B66
TDD LTE: B40
WCDMA: B1/B2/B4/B5/B8
GSM: B2/B3/B5/B8
MC904-NA:
FDD LTE:B2/B4/B5/B12/B13/B14/B66/B71
WCDMA:B2/B4/B5
WIFI2.4GHz, 802.11 b/g/n
ProtocolJT/T808-2011, JT/T808-2019
JT/T1076-2016, JT/T1078-2016

Cameras

Extended4-CH CVBS,1.0Vp-p, 75Ω, 1080P
ADASYes
DMSYes
BSDYes
360-degree panoramic viewYes
Video encodingH.264/H.265, default H.264
Video standardsPAL , NTSC
Video resolutionOptions:1080P/720P/D1
Total 1080P at 60 fps
Compression formatG.711A

Others

Power supplyDC: +9V ~ +36V
Operation Temperature-20℃ to +70℃
Operation Humidity8% to 90%
Net weight450g
Dimension195mm*183mm*60mm
CertificationRoHS
