| Camera | |
Image Sensor | 1/2.8″ progressive scan CMOS |
Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s |
Slow Shutter | Yes |
Auto-Iris | No |
| | |
Day &Night | IR cut filter |
Digital Noise Reduction | 3D DNR |
WDR | DWDR |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75° |
| Lens | |
Focal length | 2.8 mm, 4 mm |
Aperture | F2.0 |
Focus | Fixed |
FOV | 2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5° |
4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5° |
| |
Lens Mount | M12 |
| IR | |
IR Range | Up to 30 m |
Wavelength | 850 nm |
| |
| Compression Standard | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 |
Sub stream: H.265/H.264/MJPEG |
H.264 Type | Main Profile/High Profile/Baseline Profile |
H.265 Type | Main Profile |
Video Bit Rate | 32 Kbps to 8 Mbps |
| Smart Feature-set | |
Region of Interest | 1 fixed region for main stream |
| Image | |
Max. Resolution | |
Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Max. Frame Rate | 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Sub-stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
Max. Frame Rate | 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Enhancement | BLC, 3D DNR |
Image Setting | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or |
web browser |
Day/Night Switch | Auto, scheduled, day, night |
| Network | |
Alarm Trigger | Motion detection, video tampering alarm, illegal login |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
Firmware Version | V5.5.83 |
API | ONVIF (PROFILE S), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users |
3 levels: Administrator, Operator, and User |
